4FT Architectural LED Linear Light Up & Down 60/50/40/30/20W 5CCT

4FT Architectural LED Linear Light Up & Down 20/30/40/50/60W 5CCT

The 4FT Architectural LED Linear Light Up & Down 20/30/40/50/60W 5CCT is a highly versatile architectural lighting solution designed for modern commercial and professional spaces. Combining contemporary aesthetics with customizable illumination, this fixture delivers both direct and indirect lighting while allowing precise control over how the light is distributed between the upper and lower sections.

One of its standout features is the five selectable Up & Down lighting distributions, providing exceptional flexibility for different environments and design requirements. Users can select 100% Up / 0% Down, 70% Up / 30% Down, 50% Up / 50% Down, 30% Up / 70% Down, or 0% Up / 100% Down. This makes it possible to create anything from soft indirect ceiling illumination to powerful downward task lighting—or a balanced combination of both.

The fixture also offers adjustable wattage from 20W to 60W and delivers an efficient 130 lumens per watt, helping achieve excellent illumination while maintaining energy efficiency. Its 5CCT selectable technology provides 3000K, 3500K, 4000K, 5000K, and 6500K color temperature options. Even better, the Up and Down light CCT can be controlled individually, providing additional flexibility when designing layered lighting environments.

Operating on 120-277V with 0-10V dimming, this architectural linear fixture integrates easily into a wide range of commercial electrical systems and allows smooth adjustment of light output.

Flexible & Seamless Architectural Installations

Designed for creative architectural layouts, the fixture can be seamlessly linked with up to 7 fixtures without visible joint spots. Multiple configurations are possible using straight, X-shape, L-shape, and + shape connections, making it ideal for custom lighting designs in large or open spaces.

Installation options include pendant mounting, surface mounting, and wall mounting, allowing the same fixture platform to adapt to different architectural requirements. The light includes a canopy holder, linkable kit, and hanging chain for convenient installation.

The standard finish is black, with white and silver finishes available as optional choices. Motion sensor and emergency battery options are also available for projects requiring additional functionality.

Built for demanding commercial installations, this architectural LED linear light is DLC Premium certified and backed by a 5-year warranty, making it an excellent choice for offices, convention centers, lobbies, hospitals, showrooms, hotels, and other contemporary commercial environments.
